cable tray cutting machine
As a professional cold roll forming machine manufacturer, we specialize in providing efficient and reliable cable tray cutting machine solutions for global customers. Our cable tray cutting machine is designed to precisely cut cable trays after roll forming, ensuring accurate length, clean cutting edges, and high production efficiency for cable tray manufacturing lines.
| aw Material Specifications | Material Type | Galvanized / Cold-Rolled / Stainless Steel |
| Material Thickness | 0.8–2.5 mm (Customizable) | |
| Material Width | Customized according to tray size | |
| Yield Strength | G220-G250 | |
| Roll Forming System | Forming Stations | 18–24 stations |
| Roller Material | GCr15, heat treated | |
| Shaft Material | 45# steel, heat treate | |
| Shaft Diameter | Φ70–90 mm | |
| Drive System | Chain drive | |
| Punching System | Punching Type | Hydraulic Punching |
| Punching Position | Before forming | |
| Hole Type | Round / Slotted / Customized | |
| Punching Accuracy | ±0.5 mm | |
| Control System | Operation Interface | Touch Screen (CN / EN) |
| Inverter | Famous brand | |
| Electrical Components | Siemens or Schnedier | |
| Data Memory | Parameter memory | |
| Motor & Hydraulic System | Main Motor Power | 11 kW *3 sets |
| Hydraulic Power | 7.5 kW | |
| Power Supply | 380V / 50Hz / 3Ph (Custom) | |
| Hydraulic Oil | 46# Anti-wear Hydraulic Oi | |
| Production size | Line Length | 35 meters |
| Machine Width | 2.5 meters | |
| Machine Weight | 25ton |
The cable tray cutting machine is widely used in cable tray production for electrical installations, data centers, industrial plants, and commercial buildings. It works seamlessly with cable tray roll forming machines and cable tray production lines, forming a complete and automated manufacturing system. By integrating hydraulic cutting or servo-controlled cutting technology, the cable tray cutting machine guarantees smooth and burr-free cutting results, even during high-speed operation.
Our cable tray cutting machine features a heavy-duty steel structure that provides excellent stability and durability. High-quality cutting blades made from premium alloy steel are heat-treated to ensure long service life and consistent cutting performance. The cutting system is designed to maintain precise length control, reducing material waste and improving overall production efficiency.
Customization is a major advantage of our cable tray cutting machine. Feeding width, cutting thickness, cutting length, and cutting speed can all be customized according to customer requirements. The machine supports various cable tray types, including ladder type, perforated type, and solid bottom cable trays. It is compatible with materials such as galvanized steel, stainless steel, and cold-rolled steel, with thickness ranges typically from 0.8 mm to 2.5 mm. Voltage, frequency, and electrical standards can also be customized to meet different country regulations.
To ensure easy operation and reliable performance, the cable tray cutting machine is equipped with a PLC control system and a user-friendly touchscreen interface. Operators can easily set cutting length parameters, monitor machine status, and adjust production settings in real time. When machine issues occur, our experienced engineers provide real-time video technical support, helping customers quickly troubleshoot and minimize downtime without waiting for on-site service.
Each cable tray cutting machine is strictly tested before delivery to ensure stable operation and compliance with international quality standards. In addition to machine manufacturing, we provide comprehensive after-sales services, including installation guidance, operation training, spare parts supply, and long-term technical support.
With precise cutting accuracy, flexible customization, durable structure, and reliable remote support, our cable tray cutting machine is an ideal choice for manufacturers seeking efficient and cost-effective cable tray cutting solutions.
Whatsapp:0086 18526079110
E-mail:Kevin@hx-machinery.com
HOPEX (Wuxi) Intelligent Technology Co., Ltd.: Pioneering Roll Forming Innovation Since 1996
Founded in 1996 with a dedicated R&D team for roll forming technology, HOPEX has evolved into a global force in intelligent manufacturing. Established in Wuxi in 2003, we launched our core product lines—semi-automatic purlin machines, cable tray machines, and guardrail machines—laying the foundation for our commitment to 100% customized solutions.In 2016, we doubled our team and expanded our offerings to include solar strut machines and heavy-duty leveling/slitting lines, while strengthening R&D for our flagship products. By 2022, HOPEX achieved 100% sales growth and revolutionized production through full automation, upgrading all equipment to smart manufacturing standards and growing our R&D team to 10+ experts.Today, we export cutting-edge machinery worldwide—serving Russia, Australia, India, the Middle East, Southeast Asia, and beyond—as we fully enter the global market in 2025. Our vision is clear: to be the global leader in roll forming technology, making precision engineering easier and hassle-free for industries everywhere.
Q: Are you a trading company or a factory?
A: We are a factory with a professional production team and service consciousness, just for exporting various types of cold roll forming machines.
Q: Can a machine produce only one style of panel profile?
A: Not complete. Suitable for a highway guardrail forming machine. It can produce more than 3 panels.
Q: How long does it take to manufacture the machine?
A: In general, the highway guardrail forming machine be completed in 20 to 45 business days. But if you need machines urgently, we can save you time.
Q: Is there quality control when producing the production line?
A: Yes, we have a team that is responsible for quality control, including the laying of raw materials, processing rolls and other parts, processing, assembly, testing, and packaging on the roll surface and shaft.
Q: What can you do if the machine breaks?
A: Our machine is warranted for 24 months. If the damaged part cannot be repaired, we can send a new part to replace the damaged part, but you will need to pay the courier fee yourself. If the warranty period is exceeded, we can resolve the issue through negotiation, and we provide technical support for the entire life cycle of the device.
