perforated cable tray roll forming machine
As a professional cold roll forming machine manufacturer, we specialize in designing and supplying high-performance perforated cable tray roll forming machine solutions for customers worldwide. Our perforated cable tray roll forming machine is engineered to produce high-quality perforated cable trays used in electrical installations, data centers, industrial plants, and commercial construction projects.
| aw Material Specifications | Material Type | Galvanized / Cold-Rolled / Stainless Steel |
| Material Thickness | 0.8–2.5 mm (Customizable) | |
| Material Width | Customized according to tray size | |
| Yield Strength | G220-G250 | |
| Roll Forming System | Forming Stations | 18–24 stations |
| Roller Material | GCr15, heat treated | |
| Shaft Material | 45# steel, heat treate | |
| Shaft Diameter | Φ70–90 mm | |
| Drive System | Chain drive | |
| Punching System | Punching Type | Hydraulic Punching |
| Punching Position | Before forming | |
| Hole Type | Round / Slotted / Customized | |
| Punching Accuracy | ±0.5 mm | |
| Control System | Operation Interface | Touch Screen (CN / EN) |
| Inverter | Famous brand | |
| Electrical Components | Siemens or Schnedier | |
| Data Memory | Parameter memory | |
| Motor & Hydraulic System | Main Motor Power | 11 kW *3 sets |
| Hydraulic Power | 7.5 kW | |
| Power Supply | 380V / 50Hz / 3Ph (Custom) | |
| Hydraulic Oil | 46# Anti-wear Hydraulic Oi | |
| Production size | Line Length | 35 meters |
| Machine Width | 2.5 meters | |
| Machine Weight | 25ton |
The perforated cable tray roll forming machine integrates decoiling, feeding, precision roll forming, hydraulic or servo punching, hydraulic cutting, and finished product output into a fully automatic production line. This continuous and stable process ensures accurate hole positioning, uniform tray dimensions, and smooth edges, making the perforated cable tray roll forming machine ideal for mass production with consistent quality.
Our perforated cable tray roll forming machine is built with a heavy-duty steel frame to ensure long-term stability and minimal vibration during operation. The forming rollers are manufactured from high-quality alloy steel, processed by CNC machining and heat treatment to provide excellent wear resistance and extended service life. This robust design allows the perforated cable tray roll forming machine to operate reliably even under high-speed production conditions.
Customization is one of the key strengths of our perforated cable tray roll forming machine. Feeding width, roll forming thickness, perforation hole shape and spacing, cutting length, and production speed can all be customized according to customer drawings or technical requirements. The machine is compatible with various materials, including galvanized steel, stainless steel, and cold-rolled steel, with common thickness ranges from 0.8 mm to 2.5 mm. Voltage, frequency, and electrical standards can also be customized to meet different country requirements.
To ensure easy operation and intelligent control, the perforated cable tray roll forming machine is equipped with an advanced PLC control system and a user-friendly touchscreen interface. Operators can easily adjust parameters, monitor real-time production status, and store multiple product programs. When machine issues occur, our experienced engineers provide real-time video technical support, helping customers quickly troubleshoot and resume production without waiting for on-site service.
Each perforated cable tray roll forming machine is strictly tested before delivery to ensure stable performance and compliance with international quality standards. In addition to machine manufacturing, we offer comprehensive after-sales services, including installation guidance, operator training, spare parts supply, and long-term technical support.
With high efficiency, precise perforation accuracy, flexible customization, and reliable remote service, our perforated cable tray roll forming machine is the ideal solution for manufacturers seeking efficient and cost-effective perforated cable tray production equipment.
Whatsapp:0086 18526079110
E-mail:Kevin@hx-machinery.com
HOPEX (Wuxi) Intelligent Technology Co., Ltd.: Pioneering Roll Forming Innovation Since 1996
Founded in 1996 with a dedicated R&D team for roll forming technology, HOPEX has evolved into a global force in intelligent manufacturing. Established in Wuxi in 2003, we launched our core product lines—semi-automatic purlin machines, cable tray machines, and guardrail machines—laying the foundation for our commitment to 100% customized solutions.In 2016, we doubled our team and expanded our offerings to include solar strut machines and heavy-duty leveling/slitting lines, while strengthening R&D for our flagship products. By 2022, HOPEX achieved 100% sales growth and revolutionized production through full automation, upgrading all equipment to smart manufacturing standards and growing our R&D team to 10+ experts.Today, we export cutting-edge machinery worldwide—serving Russia, Australia, India, the Middle East, Southeast Asia, and beyond—as we fully enter the global market in 2025. Our vision is clear: to be the global leader in roll forming technology, making precision engineering easier and hassle-free for industries everywhere.
Q: Are you a trading company or a factory?
A: We are a factory with a professional production team and service consciousness, just for exporting various types of cold roll forming machines.
Q: Can a machine produce only one style of panel profile?
A: Not complete. Suitable for a highway guardrail forming machine. It can produce more than 3 panels.
Q: How long does it take to manufacture the machine?
A: In general, the highway guardrail forming machine be completed in 20 to 45 business days. But if you need machines urgently, we can save you time.
Q: Is there quality control when producing the production line?
A: Yes, we have a team that is responsible for quality control, including the laying of raw materials, processing rolls and other parts, processing, assembly, testing, and packaging on the roll surface and shaft.
Q: What can you do if the machine breaks?
A: Our machine is warranted for 24 months. If the damaged part cannot be repaired, we can send a new part to replace the damaged part, but you will need to pay the courier fee yourself. If the warranty period is exceeded, we can resolve the issue through negotiation, and we provide technical support for the entire life cycle of the device.
